The "Micro Burn-in & Technology" Company and Team is committed to the design, manufacture and operation of reliability test systems for electronic components. The founders and principles of Micro have decades of experience in supplying reliable and efficient burn-in and life-testing systems and instruments to both component manufacturers and to users of high reliability components. more....
- On-staff project designers
- Material acquisition specialists
HT ACOL - 300 position High Temp ACOL System
Up to 3Amps. forward Current
1200 Volt Reverse Voltage
150 Degrees Celsius Temperature
Welcome to the Micro Burn-in & Technology, Inc. Website. The founders and principles of Micro have decades of experience supplying reliable and efficient burn-in and life testing systems and instruments to both component manufacturers users of high reliability components.
PO Box 1298, Poway, CA 92074 Office Voice: (760) 746-2010
HV ACOL - 960 position
1Amp. Forward Current
3000 Volt Reverse Voltage
Diode Burn-in System
ACOL - Power Rectifier Burn-in Module
Up to 4 Amps Forward Current
1200 Volts of Reverse Voltage
Up to 1200 DUTs Capacity per System
48 Individual Controls
The Micro Team provides engineering and project design and manufacturing services to small businesses and Fortune 500 companies alike. We handle everything from start to finish: conception, design, project planning, materials aquisition, fabrication, assembly, field services, and more. more....
CE9051 - Capacitor HALT Tester
Fully Computer Controlled tester for Ceramic and Tantalum Caps, Leaded and Chip.
Temputature: 75 - 250 Degrees C. (Higher and Lower Temperatures are also Available).
Bias Voltage: 0 to 1000 VDC.
Measurment: 10 pA to 1mA.
Capacity: 1200 Devices in 12 individual Trays with 12 independent Voltage settings.
Model MBS 10KP-400M
Capacitor Life Test/Burn-In WEIBULL System
Temputature: 75 - 200°C. (Higher and Lower Temperatures are also Available).
Bias Voltage: 0 to 600 VDC (Higher Voltages Available).
Measurment: Fused & Computer Monitored up to 1600 positions, Fused up to 10,000 positions, this system could be configured in one or multiple smaller Chambers.
Capacity: 80 Devices per tray, 20 to 240 individual Trays (in one or multiple Chambers) with up to 10 independent Voltage settings.
Priced less than 1/2 of the original price
DM500, DM504 and DM505 Instrument Boards: We have limited but overstock quantities of DM5xx Instrument Boards Fully Tested, Calibrated and full Warranty for one year, ready to ship.
PE9000 and PE9000A System: Spare parts such as Temperature Controllers, Over-temp Controllers, Logic Supplies, Heater Elements and much more, fully tested and full Warranty ready to ship.
